Product Features

• Dual output, field selectable 12 or 24VDC via clearly marked toggle switch
• Supplies 1 full AMP continuous current output, even while charging back-up batteries
• SPDT AC monitoring output allows for remote monitoring of the power supply's 110VAC input
• Separate voltage inputs for load and battery allow the batteries to charge at a higher output while the load remains at exactly 12 or 24VDC
• LED indication (AC and DC) showing power supply status
• UL Listed low current fire alarm disconnect requires only a minimum size fire alarm relay and wire gauge
• Polyswitch 2A breaker allows for large short duration inrush current if batteries are installed (approximately 20A for 1 second)
• Line voltage and DC fuses
• Sealed lead acid-gel battery charging capability (battery not included)
• UL Class 2, linear regulated power supply provides the cleanest power available sensitive, active safety and security devices
• UL Listed
• MagnaCare^® lifetime replacement, no fault warranty

Specification Data

Voltage Adjustment: 12V/24V selector switch
Input Voltage: 120VAC - BPS-12/24-1
Output Current: 1 Amp
Operating Temperature: 32 to 105F [0 to 40C]
Shipping Weight: 9 lbs.
