Each Pyro S unit is equipped with a USB-C port that powers the unit and supports plug-and-play UVC operation, allowing it to seamlessly connect to a computer for streaming and conferencing applications. A built-in frequency scanner lets you select the clearest transmission frequency, with a bright LCD for easy configuration. Besides the multifunction USB-C port, each unit can be powered using a separately available locking DC power adapter or an L-series type battery with an optional battery plate.

Long Distance, High Quality

The Pyro S Wi-Fi broadcast technology enables one transmitter to connect to four receivers with stable signals, offering more flexibility when additional monitoring needs emerge on set. When Broadcast mode is activated, the transmitter can transmit signals to at most four receivers, and the line-of-sight range reaches 650'. When Broadcast mode is deactivated, the transmitter can transmit signals to at most two receivers and two mobile devices, and the line-of-sight range extends up to 1300'.

Strong Signal Strength

At a stable transmission range of up to 1300', the Pyro S features latency as low as 50ms. Compared to the Mars series, whose transmission range extends at the cost of image quality and latency, the Pyro S excels with increased transmission distance while preserving video quality and minimising latency. The receiver combo also provides two modes for users to tip the balance between image quality and latency, with HD mode for better image quality with bitrate at up to 12 Mb/s and Smooth mode for a dynamic change in latency.

Crisp and Sharp Images

With up to 4K30 transmission capabilities via HDMI and 1080p60 via SDI, the Pyro S transmits images with superior clarity, detail, and realism, making it a great choice for professional applications like broadcast and filmmaking.

USB Video Class

UVC allows seamless compatibility with a wide range of devices, such as computers, without requiring additional drivers or software installations. This plug-and-play feature simplifies setup and operation, making it convenient for users in various scenarios, such as live streaming and video conferencing.

RTMP

Input your wireless key and connect a network card to stream video directly to live platforms like Zoom, YouTube, Twitch, and TikTok.

Smart Channel Scan

Upon startup, Pyro S automatically chooses a high-quality frequency channel, optimising the user experience from the outset. Additionally, users can activate the smart channel scan function on the receiver to view real-time feedback on the frequency status, thus ensuring an uninterrupted and reliable experience.

Easy Setup

The Pyro S supports preset grouping and pairing, eliminating the need for users to repetitively and manually set up the receivers.

Continuous Power, Multiple Options

In addition to DC input and NP-F batteries, the Pyro S also supports a USB-C power supply (5-12V). A USB power supply option provides convenience, especially when using stabilisers, as it eliminates the need for larger NP-F batteries, reducing overall weight and enhancing maneuverability.

Specifications

• Wireless Receiver
• Transmit UHD 4K30 Video up to 1300'
• HDMI/SDI Inputs and Outputs
• 2.4 and 5 GHz Frequency Bands
• Supports UVC and RTMP for Streaming
• 650' Transmission in Broadcast Mode
• Smart Channel Scanning, Bright LCD
• Low 50 ms Latency, 12 Mb/s Bit Rate
• DC, L-Series, and USB-C Power Options

What's Included

1 x Hollyland Pyro S 4K HDMI/SDI Wireless Video Receiver
1 x Hollyland Pyro-S TX
1 x Hollyland Pyro-S RX
7 x Pyro-S Antenna
1 x Power Adaptor
1 x Cold Shoe Adaptor
