SPECIFICATIONS

Overview
Height of Cabinet	24.5" (62 cm)
Height to Hinge Cap	24.63" (63 cm)
Width	18.5" (47 cm)
Depth	17.75" (45 cm)
Depth with door at 90°	34.5" (88 cm)
Capacity	1.8 cu.ft. (51 L)
Defrost Type	Manual
Door	White
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	0.8
Voltage/Frequency	115 V AC/60 Hz
Weight	43.0 lbs. (20 kg)
Shipping Weight	45.0 lbs. (20 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Freezer
Door Swing	RHD
Reversible	Yes
Interior Height	18.63" (47 cm)
Interior Width	13.38" (34 cm)
Interior Depth	13.0" (33 cm)
Shelf Type	Wire
Shelf Qty	2
Thermostat Type	Dial
Refrigerant Type	R600a
Refrigerant Amount	0.8 oz.
Level Legs	2
Compressor Step Height	8.0" (20 cm)
Compressor Step Width	13.38" (34 cm)
Compressor Step Depth	5.75" (15 cm)

AVAILABLE UPGRADES

Handle

CP Full-Length Copper Pipe Handle

Factory-installed full-length handle made from pure copper for antimicrobial protection

TBC Copper Towel Bar Handle

Factory-installed handle made from pure copper for antimicrobial protection

Exterior

Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	DL1 - Factory installed data logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac
DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management	HG - Hospital grade cord Add a hospital grade cord equipped with green dot plug with the HG suffix
Latch for door Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.	LHD - Left hand door swing Door reversal to left hand swing
ODA - Open door alarm Add an open door alarm to audibly buzz when the door is left ajar.	SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option
TT - Installed thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order	Extra key Extra keys available for purchase
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Lock

AC Keypad

Keypad door lock powered by appliance power cord for keyless security

KEYPAD

Battery-powered keypad door lock installed for keyless security

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or

California residents:

WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to .
Note: Nickel is a component of stainless steel.

FEATURES

Compact dimensions
Sized for easy use on top of counters

Fully finished cabinet
Allows the unit to be used freestanding

Manual defrost
Static cooling system for improved temperature stability

Adjustable thermostat
Dial thermostat located inside the unit

Factory installed lock
Keyed lock for a secure interior

Reversible door
User-reversible door swing allows for more flexibility in placing the unit

Removable shelves
Wire shelves can be removed to accommodate different sizes or for easy cleanup

Flat door liner
Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials

One piece interior liner
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices

100% CFC free
Environmentally friendly design without ozone-damaging chemicals

DESCRIPTION

Accucold by Summit Appliance carries a quality selection of compact freezers for general purpose use in medical facilities.The FS30L is a compact 1.8 cu.ft. all-freezer designed for countertop use. It comes in a white exterior finish, with a factory installed lock on the user-reversible door. The interior includes removable wire shelves for optimum circulation and a one-piece interior liner to ensure easy cleanup. The dial thermostat is located inside the unit. This freezer is manual defrost and operates at an average temperature of -20ºC.With reliable construction and a convenient size, the FS30L is the ideal freezer for storing select items in institutional facilities. This unit can also be ordered with more advanced medical features, including a digital thermostat, self-closing door, temperature alarm, and more.Note: This product is intended for a wide variety of basic storage applications. Storage of high-value vaccines, life science materials, and medical/clinical biologicals require a product offering tighter temperature control and/or alarms, monitoring, and backup. For more information, browse Accucold's purpose-built line or contact our product specialists at 1-888-4-MED-LAB.
